型番：　メーカー：Intense Photonics　商品コード：L002232

1550 nm Laser | 12W

1550 nm Laser | 12W
1550 nm Laser | 12W
1550 nm Laser | 12W
1550 nm Laser | 12W

波長: 1550nm-1550nm
出力: 12W-12W
パッケージ: TO-can
テクノロジー: pulsed

1550nm IR (1550 nm laser) from Intense Photonics are Short Pulse Eye Safe Lasers for Industrial and Military Applications The HPD Series 2400 are high peak power, eye safe, 1550 nm pulsed diode lasers designed for applications that require powers up to 33 mW/µm of junction length at 200 ns Pulse Width. These broad area emitters have excellent reliability and good quantum efficiency. Single emitters from 150 µm to 350 µm junction length are standard. Other wavelengths from 886 nm to 1100 nm, along with stacked arrays, are available on special order. The 1550 nm laser may be overdriven at narrower pulse widths using Pod = Po * (200/Pwd) 1/2. Standard packages include 5.6MM, 9mm, TO18 coaxial, and TO5 twin lead. Options include fiber pigtails. Applications include hand held rangefinders, laser speed detectors, ceilometers, weapons simulation, and proximity fuses.
