型番：FiberMax635 Low Power　メーカー：Blue Sky Research　商品コード：L003319

635nm / 1, 5, 20mW　Low Power Fiber Pigtailed Red Laser Module

635nm / 1, 5, 20mW　Low Power Fiber Pigtailed Red Laser Module
635nm / 1, 5, 20mW　Low Power Fiber Pigtailed Red Laser Module
635nm / 1, 5, 20mW　Low Power Fiber Pigtailed Red Laser Module
635nm / 1, 5, 20mW　Low Power Fiber Pigtailed Red Laser Module
635nm / 1, 5, 20mW　Low Power Fiber Pigtailed Red Laser Module
635nm / 1, 5, 20mW　Low Power Fiber Pigtailed Red Laser Module

FiberMax635 Low Power データシート.pdf

波長: 630nm-645nm
出力: 1.5mW-20.0mW
電流: 30mA-130mA
電圧: 2.2V-2.8V
テクノロジー: Fiber Pigtailed Red Laser Module

< Description >
FiberMax635 is a fiber-pigtailed red laser module delivering superior performance for today’s demanding electro-optic applications. Based on Blue Sky Research laser packaging technology, the FiberMax635 provides excellent coupling efficiency and stability in a cost effective package. The thermally stable design of the FiberMax635, based on our standard FiberMAX packaging technology, is a proven, stable package with many thousands of lasers operating in demanding applications. The units are offered with Multimode, Polarization Maintaining Single Mode or Single Mode fiber, 3mm or 0.9mm jacketing and a range of collimator options.
