型番：　メーカー：VERTILAS GmbH　商品コード：L001930

VCSEL Laser, 1310 NM - 1550 NM

VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM
VCSEL Laser, 1310 NM - 1550 NM

波長: 1310nm-1550nm
出力: 1mW-1mW
パッケージ: TOSA
テクノロジー: VCSEL Laser, CWDM, 1-10Gbps

1310nm, 1490nm, 1550nm The VERTILAS communications laser products are single-mode VCSEL laser diodes (Vertical Cavity Surface-Emitting Laser) operating at data rates from 1 Gbps up to 10 Gbps. Packaging options include TO, receptacles, pigtails and other customer specific solutions. This high-performance single-mode VCSEL laser technology features a very low threshold current and provides an optical output power of up to 4.0 mW. The lasers feature fast rise and fall times, low threshold voltage, excellent SMSR performance and extremely low power dissipation. This VCSEL is well suited for high-performance, single-mode and multi-mode communications solutions with a data-rate of up to 10G Gbps. The low drive current enables simplified system design and reduces power dissipation and system cost.

Key Features
- Single-mode VCSEL
- TO-46 form factor
- 1 Gbps to 10 Gbps data rate product versions
- Operating temperature: -20 to +70 °C, extended –20 to +85°C
- Low power consumption: Sub 30 mW
- Enables SFF modules with sub 1 W power budget
- Low drive currents and low threshold voltage
- Integrated monitoring diode optional
- Various packaging and TOSA options
