型番： メーカー：FITEL 商品コード：L002388
1510nm, 20mW, butterfly
波長: 1510nm-1510nm
出力: 20mW-20mW
パッケージ: butterfly
テクノロジー: DFB Laser
1510nm FITEL Laser series of DFB laser module is designed for supervisory channel. The polarization maintaining fiber pigtail enables to directly connect a modulator without polarization control. The polarization state of output laser beam is maintained to a consistent orientation. A strained multi-quantum well DFB laser diode chip is integrated with optical isolator, thermo-electric cooler (TEC), thermistor and power monitor photodiode in an industry standard hermetically sealed 14 pin butterfly package. This laser module complies with telecom requirements described in TelcordiaTM GR-468 and is manufactured in an ISOTM9001 certified production line.
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 京都府 | 株式会社光響 | |
