型番：20.220.00018、20.220.00019、20.220.00020　メーカー：Artifex Engineering　商品コード：L003792

OPM150P 10G/10UVS/10VIGA-Detector

波長: 250nm-1600nm
出力: 1μW-250mW

< Description >
The head mechanics are designed to be compatible with various common optomechanics systems to allow simple integration. Various adapters for tube systems, camera objectives and optical fibres are available to further enhance the ease of integration. This detector is compatible with the OPM150 series of optical power meter. When connected to the OPM150 base unit, each head is automatically recognized and its individual calibration data are uploaded to the system. In addition, the user may load up to 5 separate filter curves. Thus the dynamic range and functionality of the unit can be expanded while ensuring proper calibration.

・OPM150P10G-Detector (20.220.00019)
　A 10mm inner diameter integrating sphere encorporating a germanium photodiode.

< Specifications >
Internal diameter: 10mm
Wavelength range: 800-1550nm
Input aperture: ø3.5mm
Minimum measureable power: 125µW (at 1550nm)
Maximum measureable power: 250mW (at 1550nm)
Maximum outer dimensions: ø30mm x 30mm

・OPM150P10UVS-Detector (20.220.00018)
　A 10mm inner diameter integrating sphere encorporating a UV-enhanced silicon photodiode.

< Specifications >
Internal diameter: 10mm
Wavelength range: 250-1100nm
Input aperture: ø3.5mm
Minimum measureable power: 2µW (at 600nm)
Maximum measureable power: 200mW (at 600nm)
Maximum outer dimensions: ø30mm x 30mm

・OPM150P10VIGA-Detector (20.220.00020)
　A 10mm inner diameter integrating sphere encorporating a visible enhanced InGaAs photodiode.

< Specifications >
Internal diameter: 10mm
Wavelength range: 400-1600nm
Input aperture: ø3.5mm
Minimum measureable power: 1µW (at 1550nm)
Maximum measureable power: 250mW (at 1550nm)
Maximum outer dimensions: ø30mm x 30mm

【Accessories】
Calibrated diffuse reflecting attenuators: OD1
Adapters for tube systems
Adapters for fibre inputs: FC, SMA, LC, ø1.25 ferrule
