型番：773 メーカー：Analog Modules 商品コード：L003646
HIGH CURRENT PULSED LASER DIODE DRIVER
電流: -118A
電圧: 2V-5V
パルス幅: 100 µs to 3 ms
重さ: 2.1 oz
DESCRIPTION:
The Model 773 is a highly compact, low voltage DC input power converter/laser diode driver designed to supply pulsed high current for laser diode-stack loads. Pulsed output current is 118A with ≦25μs risetime into diodestacks of 2 to 5V at an average power to the load of 1.0W. The driver weighs 2.1 oz. in a compact package and is ideally suited for rangefinding applications. The unit does not require a heatsink and offers open circuit and short circuit protection.
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 株式会社オプトサイエンス | ||
