【Features】

Drive up to 20A in Master/Booster mode
Single supply operation: +5V to +30V
Includes cabling to master
Small size: 3.0" x 3.2" x 1.1"
Independent Current Limit

TIME-TESTED RELIABILITY
The PTC-CH Series Chassis Mount Temperature Controllers deliver the precision performance and long-term reliability you expect from a Wavelength Electronics temperature controller. PTC-CH Series controllers are found in such diverse applications as particle and droplet measurement, manufacturing machine vision systems, biomolecular interaction analysis, and more. They are CE certified.

VERSATILE AND EASY TO USE
PTC-CH controllers are available in different models so you can choose the one that best suits your application:

PTC2.5K-CH delivers up to ±2.5 A output current
PTC5K-CH for applications requiring up to ±5 A
PTC10K-CH drives up to ±10 A
PTC10K-SL can be tied to the 10 A driver to deliver a combined ±20 A output current
The PTC-CH controllers operate from a single power supply between 4.5 V and 30 V. The linear bipolar controller drives a Peltier thermoelectric cooler or a resistive heater, and the chassis-mount package integrates easily into OEM applications.

PTC-CH controllers interface with a variety of temperature sensors, and the bias current is adjustable in order to maximize controller sensitivity and stability for your application.

The compact chassis-mount design simplifies heatsinking and requires minimal space. PTC-CH controllers are quick to configure for your prototype project, and there are no surprises when it’s time to integrate the controller into the final design.

If you are using a Quantum Cascade Laser or need low noise performance with a laser diode, we offer the PTC-CH nested in the QCL OEM drivers.

PRACTICAL FEATURES FOR REAL-WORLD CONDITIONS
Built-in features make your product more robust to real-world operating conditions and minimize your electronics overhead:

If the optional remote temperature setpoint signal is lost, the controller defaults to a standard “safe” temperature setpoint (25ºC when a 10 kΩ thermistor is used). The safe temperature can be changed at the factory; call for details.
An on-board trimpot is used to set the output current limit to prevent over-driving the TEC, and helps protect your load from thermal runaway situations.
Proportional gain is easily adjusted with an on-board trimpot.
Low temperature coefficient design remains stable across a wide range of ambient conditions.
When used with Wavelength’s laser drivers, such as the PLD Series, these temperature controllers provide stable and reliable performance that sets your system apart from your competitors’ and keeps your customers satisfied.
