型番：VPSL-0658-035-x-5-A　メーカー：Blue Sky Research　商品コード：L003348

658nm / 35mW　VPS Laser Diode [TO-can]

波長: 645nm-665nm
出力: 30mW-35mW
電流: 80mA-120mA
電圧: 2.1V-3.0V
パッケージ: TO-can
形状: 円
拡がり角: 7, 8.5, 10.5 deg

< Description >
The VPSL-0658-035-x-5-A is a 0.65 µm band, AlGalnP index guided, laser diode with a multiquantum well (MQW) structure. It is suitable as a light source for large capacity optical disc memories, such as DVD-RAM, and various other types of optical equipment. Combined with an integrated, internal, beam correcting optic and encased in a hermetic sealed package, this is a high-performance, highly reliable, and long life laser diode.

< Features >
Built-in monitor photodiode
Circular, diverging beam, NA approximately 0.11 at 1/e2 point
Diffraction limited wavefront
35mW CW optical power, 50mW pulsed (50% duty, pulse < 1μs)
Standard 5.6 mm form factor
