型番：TEAF-0.40-0.60-2FP、TEAF-0.45-0.7-S-2FP、TEAF-0.9-1.2-UH-2FP、TEAF-1.2-1.7-UH/EH-2FP、TEAF-1.5-1.65-UH/EH-2FP、TEAF-1.1-2.1-S-2FP　メーカー：Brimrose Corporation of America　商品コード：L003283

Dynamic Tunable Bandpass Filters

FCAOTF　データシート.pdf

波長: 400nm-2100nm

FREE SPACE AO DEVICESはこちら
OEM & LAB VERSION RF DRIVERSはこちら

The Dynamic Tunable Bandpass Filter adjusts the center wavelength of a narrow band of light over a 100 - 200nm range. It offers very high resolution of ~1.5nm and either single or simultaneous multiple wavelength selection. It is able to precisely and rapidly adjust the wavelength and intensity of the diffracted/filtered light by varying the frequency and RF power.

Brimrose offers both free-space and fiber-coupled configurations. AOTFs are used widely in numerous optical systems and applications, especially in industrial or process control near-infrared (NIR) spectroscopy applications.

< KEY FEATURES >
Compact Size
No O-rings
Low Insertion Loss
Low Power Consumption
Narrow Bandwidths
Excellent Tuning Resolution
Hermetically Sealed
Broad Tuning Range
SM, SM/PM, MM Fiber Coupling Options
Custom Configurations Available
Ideal for Real-Time NIR

< APPLICATIONS >
Dense WDM Transmission Systems
Laboratory Test and Measurement Systems– tuning the center wavelength of broadband sources (white light sources or LEDs)
Other OEM Applications
