メーカー希望小売価格: $1,735.00 電流: 15A-15A
電圧: 48V-48V

Product Overview:
The OsTech OEM Laser Diode Controller is a 15 Amp, 48 Volt, laser driver current source. It offers researchers and industrial users multiple features such as high stability and 4 layers of integrated laser protection. Simple to use LabVIEW drivers are available to make set-up and operation fast and straight forward.
These OsTech drivers are powered by an input voltage of 98~230 VAC with power factor correction. The high output power ranges from 300 Watts to 1200 Watts. The laser diode current ranges up to 48 Volts for controller multi element devices and also for controlling multiple laser diode connected in series mode.
Like all other OsTech precision laser drivers and temperature controllers, an RS232 interface, with an optional USB converter, for controlling and monitoring is integrated. CW or pulse modes of operation are available. A pulse generator is also integrated into the unit for reducing the number of instruments required to perform QCW / pulsed mode. External digital or analog modulation is also supported.
The typical rise time of the QCW mode for these drivers is 25 µs. Faster rise times are available on request. Rise times less than 5 µs are achievable if the load and cabling are optimized for fast pulses. Additionally, up to two thermo-electric temperature controller circuits can be integrated into the chassis.
This device features Photo Diode Power monitoring, pilot laser supply and adjustable external fan support for controlling the temperature of a remote heat sink.
OsTech has been developing and manufacturing electronic control systems for laser diodes since 1998. They have developed a wide range of laser driver current sources as well as controls for peltier coolers and cooling blocks.
