型番:CB650-10-24(20X80)60DEG-C3000-G メーカー:Picotronic GmbH 商品コード:L003625

10mW Red Isolated Cross Lasermodule (60DEG-C3000-G)

メーカー希望小売価格: €193,19 波長: 650nm-
出力: 10mW-
電流: 2mA-25mA
電圧: 21.6V-26.4V
パッケージ: MODULE
テクノロジー: Cross Laser
拡がり角: B - 0.3 mrad

Isolated cross lasermodule, red, 60°, 650nm, 10mW, 24V DC, 20x80mm, class 2

• Operating Voltage 24 V DC
• Laser Class 2
• Uniform line thickness
• High Power
• Small laser head

< Main Parameters (*) >
Wavelength typ 650 nm
Optical Output Power typ 10 mW
Operating Voltage min 21.6 typ 24 max 26.4 V DC
Operating Current min 2 typ 10 max 25 mA
Operating Temperature min -20 max 50 °C
Storage Temperature min -40 max 80 °C

< Main Data >
Warranty 1 years

< Technical Parameters >
Lifetime > 10,000 h
RoHS yes

< Optical Parameters >
Beam Shape Cross
Laser Class 2
Divergence B - 0.3 mrad
Fan Angle 60 °
Line Thickness <1.5mm@3m
Operating Distance 3 m
Optics glass lens AR coated
Laser technology Single Mode Diode
Protection Lens no
Focus fixed (3000mm)

< Electrical Parameters >
Potential of Housing isolated
Stripping of cable cover 50 mm

< Mechanical Parameters >
Size Ø20x80 mm
Material aluminium
Cable length 3,000 mm
Wire type 22AWG, black, 3,6mm
Output Aperture 5.5 mm
Housing Color black
Weight 98 g
Stripping of wire 5 mm

(*) Over the complete operating temperature range
