型番：　メーカー：三菱電機株式会社　商品コード：L002362

1310nm, 150mW, TO-can

1310nm, 150mW, TO-can
1310nm, 150mW, TO-can
1310nm, 150mW, TO-can
1310nm, 150mW, TO-can
1310nm, 150mW, TO-can
1310nm, 150mW, TO-can
1310nm, 150mW, TO-can
1310nm, 150mW, TO-can

波長: 1310nm-1310nm
出力: 150mW-150mW
パッケージ: TO-can
テクノロジー: DFB Laser

1310nm ML711series are DFB (Distributed Feedback) laser diodes emitting light beam around 1310nm. They are well suited for light source in long distance digital transmission system. They are hermetically sealed devices with the photodiode for optical output monitoring.

APPLICATION:
- 1.25Gbps digital transmission system

FEATURES:
- Homogeneous grating (AR/HR facet coating) structure DFB
- Wide temperature range operation ( -40 to 85ºC )
- Low threshold current (typical 6mA)
- High speed response (typical 0.1nsec)
- 5.6mm TO-CAN package
- Flat window cap, Ball lens cap, or Aspherical lens cap
