型番：　メーカー：Xiton Photonics GmbH 　商品コード：L002697

Q-Switched Laser, Nanosecond, 193nm, 1µJ

Q-Switched Laser, Nanosecond, 193nm, 1µJ
Q-Switched Laser, Nanosecond, 193nm, 1µJ
Q-Switched Laser, Nanosecond, 193nm, 1µJ
Q-Switched Laser, Nanosecond, 193nm, 1µJ

波長: 193nm-193nm
テクノロジー: Q-Switched Laser

Q-Switched laser from Xiton Photonics is a diode pumped laser with TEM00 Beam Profile. The laser was designed for applications in 193nm metrology, Spectrometer calibration, Interferometry and Injection seeding of Excimer lasers. The Q-Switch laser features include Sealed housing, Slot mounted laser diode, Maintenance-free thermo-electrical heat management, and optional Integrated Spectrometer for
online wavelength control. Power supply is designed to be integrated into 19"-rack with integrated chiller. Nanosecond laser pulse duration is less then 10ns with pulse-to-pulse fluctuations less then 3% with a pulse repetition interval of 6kHz. System can be controlled by a remote computer and includes LabVIEW drivers. Q-Switch laser with 193nm and output energy up to 1µJ.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 株式会社日本レーザー
