型番： メーカー：Finisar Corporation 商品コード：L001966
1310nm, 20mW, Fabry-Perot, 10Gbps
波長: 1310nm-1310nm
出力: 20mW-20mW
パッケージ: TOSA
テクノロジー: Fabry-Perot, 10Gbps
1310nm The HFE6x62-561 is specifically designed for applications based on the IEEE 10GBASE-LRM optical standard. The TOSA is designed to meet the fiber launch conditions specified for the multimode and single mode optical fiber options. Excellent optical performance is achieved by matching the electrical characteristics of the TOSA and laser to the external circuitry. Separate, differential laser bias and modulation pins significantly reduce the amount of electrical power required at the module level, and help to reduce the overall electro-magnetic
emissions. The TOSA is designed to be paired with the linear ROSA HFD6x40-417 available at ww.finisar.com/aoc.php.
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 株式会社マクニカ クラビス カンパニー | ||
