型番： メーカー：QD Laser 商品コード：L000532
660nm Laser Diode, 100mW
波長: 660nm-660nm
出力: 100mW-100mW
パッケージ: TO-can
テクノロジー: Fabry-Perot
660nm The QLF063A/QLF063D are 660 nm quantum well laser devices designed for high output power application. The laser diode is mounted into a TO-56 header including a monitor PD and hermetic sealed with a flat glass cap.
FEATURES:
- 660 nm FP-LD
- 5.6mm TO-CAN package
- High output power of 100mW
- High slope efficiency
- Including monitor PD
APPLICATIONS:
- Industrial laser markers
- Measuring instruments
- Life science applications
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 京都府 | 株式会社光響 | |
