型番： メーカー：QSI 商品コード：L000686
808nm Laser Diode, 200mW
波長: 808nm-808nm
出力: 200mW-200mW
パッケージ: TO-can
テクノロジー: n/a
808nm QSI Lasers offers the model QL80R4S-A/B/C/D/E-Z3, which are MOCVD grown 808nm band laser diodes with a quantum well structure. These devices offer optical output power of up to 200mW from a hermetically sealed 5.6mm TO-can package. These devices are used extensively in applications such as solid state laser pumping and medical applications.
KEY APPLICATIONS:
The key applications referenced on the attahced data sheet include solid state laser pumping, medical product applications and industrial product applications.
KEY FEATURES:
- Wavelength: λp = 808 nm
- Optical Output Power: 200 mW (CW)
- Package Type: TO-18 (φ 5.6 mm)
- Polarization: TE (Electric Field Parallel to the Junction Plane)
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 三基光学館 | ||
