型番： メーカー：QD Laser 商品コード：L001706
1064nm Laser Diode, DFB
波長: 1064nm-1064nm
出力: 50mW-50mW
パッケージ: Butterfly
テクノロジー: DFB Laser, Pulsed and CW
1064nm DFB laser diodes from QDLaser are offered in industry standard butterfly packages. The QLD106L-6430 is a distributed feedback (DFB) laser for use as a seeder for fiber lasers and sensing applications. The laser is offered with a monitor PD and an integrated thermoelectric cooler. Key features of these 1064nm diode lasers include single longitudinal mode operation, fiber-pigtailed 14-pin butterfly package without an optical isolator and with polarization maintaining fiber integration. These devices are specified for CW and Pulsed modes of operation.
APPLICATIONS:
- Seeder for fiber lasers
- Sensing
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 京都府 | 株式会社光響 | |
