波長: 808nm-808nm
出力: 40W-40W
パッケージ: Pearl™ P10 Fiber Coupled Diode Lasers
テクノロジー: Fiber Coupled Module

808nm 5W Laser Diode from nLight Lasers is a single emitter device. The attached data sheet and specifications brochure list the following benefits, features and key specifications. These devices offer a power conversion efficiency (typical) of 55%. The typical operating current is specified at 2.8 Amps. The typical operating voltage is specified at 1.85 Volts with a maximum value of 1.9 Volts. These 5W devices have been designed for the diode pumped solid state market. Industry leading efficiency and reliability is achieved through nLIGHT’s proprietary single emitter diode laser integration technology. System footprint is minimized while maximizing reliability. These devices also offer a small emitting aperture, which combined with low beam divergence, make these devices the highest power family of CW visible diode lasers available. Wavelengths are available from 790nm to 830nm, including 808nm. These commercially recognized formats allow easy integration into your existing products.

nLIGHT’s diode laser design is based on the company’s proprietary MOCVD-grown laser structure, which results in highly reliable, long lifetime products. The data sheet for these 5W diode lasers point to the following key technical features: Patented nXLT™ diode protection for extended life, low-current and fault-tolerant architecture with industry-leading wall-plug efficiency. Also referenced for these devices is a narrow line spectrum and high polarization purity. Key applications include pumping applications as well as materials processing and Medical.
