型番：　メーカー：Finisar Corporation　商品コード：L000923

850nm VCSEL, 1.25Gbps

波長: 850nm-850nm
出力: 1mW-1mW
パッケージ: TO-can, ball lens
テクノロジー: VCSEL, 1.25Gbps

850nm The HFE4085-521 is a high radiance VCSEL designed to convert electrical current into optical power that can be used in fiber optic communications and other applications. As the current varies above threshold, the light intensity increases proportionally. The power monitor diode can be used with appropriate feedback control circuitry to set a maximum power level for each VCSEL. In addition, built-in power attenuation reduces the effective slope
efficiency. These combined features simplify design for high data rate communication and eye safety.
The HFE4085-521 is designed to be used with inexpensive silicon or gallium arsenide detectors, but excellent performance can also be achieved with some indium gallium arsenide detectors. The low drive current requirement makes direct drive from PECL (Positive Emitter Coupled Logic) or EML (Emitter Coupled Logic) gates possible and eases driver design. The HFE4085-521 is designed to interface with 50/125 and 62.5/125μm multimode fiber. It produces circularly symmetric, non-astigmatic, narrow divergence beams that, with appropriate lensing, fiber couple all of the emitter power.

見積りBOXへ入れる欲しい物リストに登録

メーカーWebサイトへ

価格	地域	代理店
要問い合わせ		株式会社マクニカクラビスカンパニー

850nm VCSEL, 1.25Gbps
