型番： メーカー：nLIGHT,INC. 商品コード：L000885
885nm, 80W from nLight Corporation
波長: 885nm-885nm
出力: 80W-80W
パッケージ: Pearl™ P10 Fiber Coupled Diode Lasers
テクノロジー: Fiber Coupled Module
885nm Pearl™ P72 Series
Features:
- Patented nXLT™ diode protection for extended life
- Low-current, fault-tolerant architecture
- Industry-leading wall-plug efficiency >50%
- PowerCore™ mode-stable fiber
- Plug and play compatibility with nLIGHT’s DL system
- Electrically isolated housing
Applications:
- Plastic Welding
- Soldering
- ACF Bonding
- PV Annealing
- FPD Annealing
- Marking
The Pearl™ P72 is designed for Material Processing to optimize the demanding industrial requirements of continuous performance with ease of integration. These pump lasers use a revolutionary fiber technology, PowerCore™, which delivers high-brightness, Gaussian or top-hat pump profiles to maximize overlap with the TEM00 cavity mode for efficient brightness conversion to 1 μm. The industry-leading efficiency of these pump sources is enabling compactness, reliability and simplified cooling for the next generation of solid-state laser systems. Pearl’s embedded nXLT™ single-emitter technology is resetting the benchmark for high-brightness semiconductor laser reliability.
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 丸文株式会社 | ||
