型番：　メーカー：QSI　商品コード：L000576

Laser Diode 635nm | TO-18

Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18
Laser Diode 635nm | TO-18

波長: 635nm-635nm
出力: 10mW-10mW
パッケージ: TO-can
テクノロジー: n/a

635nm The QSI Laser is a MOCVD grown 635 nm band InGaAlP laser diode with quantum well structure. It's an attractive light source, with a typical light output power of 10mW for optoelectronic devices such as Optical Leveler and modules.
♦FEATURES
- Visible Light Output : λp = 635 nm
- Low Threshold Current & Operating Current
- Optical Power Output 10mW CW
- Package Type TO-18 (5.6mmφ)
- Built-in Photo Diode for Monitoring Laser Diode

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 三基光学館
