型番：　メーカー：Quantel (LD)　商品コード：L000524

400W Laser, Pulsed Stacked Array

400W Laser, Pulsed Stacked Array
400W Laser, Pulsed Stacked Array
400W Laser, Pulsed Stacked Array
400W Laser, Pulsed Stacked Array
400W Laser, Pulsed Stacked Array
400W Laser, Pulsed Stacked Array
400W Laser, Pulsed Stacked Array
400W Laser, Pulsed Stacked Array

波長: 790nm-980nm
出力: 400W-400W
パッケージ: stack
テクノロジー: high power QCW laser stack

790nm, 980nm laser arrays - stacks offer 400W ouptup power. These lasers can be built from 1 to 19 diode bars of 60W QCW to 400W QCW. The laser diode bar arrays benefit from a fully mastered technology, with the appropriate design for improved efficiency and reliable operation. Packaging and heat-sink have been optimized to reduce the overall
thermal resistance. Assembly in a compact and rugged package, using AuSn hard solder, allows easy connection to a heat exchanger to get good thermal control. This technology of stacks has been successfully submitted to specific environmental tests requested for Space missions (long life-tests, endurance under vacuum, irradiations…) with NASA or ESA.
