型番： メーカー：Sony Corporation 商品コード：L000517
770nm, 840nm | MOCVD Diode Laser
波長: 770nm-840nm
出力: 90mW-90mW
パッケージ: TO-can
テクノロジー: n/a
770nm, 840nm The SLD301V is a gain-guided, high-power laser diode fabricated by MOCVD.
MOCVD: Metal Organic Chemical Vapor Deposition.
Features:
- High power
- Recommended power output Po = 90mW
- Low operating current
Applications:
- Solid state laser excitation
- Medical use
Structure:
- GaAlAs double-hetero-type laser diode
Operating Lifetime:
- MTTF 10,000H (effective value) at Po = 90mW, Tc = 25°C
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | ソニー株式会社 | ||
