型番： メーカー：LDX Optronics 商品コード：L000455
Semiconductor Laser 680nm, 800mW,
波長: 680nm-680nm
出力: 800mW-800mW
パッケージ: HHL, c-mount
テクノロジー: High Power Single Emitter
680nm LDX Optronics 800 mW Laser Diode:
- High Power CW Operation- 800 milliwatts
- High Brightness: 150 µm
- Wavelength 680 ±5 nm Standard
The LDX-2815-680 laser diode is a high brightness, high power, visible red laser diode. These AlGaInP broad-area, gain-guided lasers are produced using MOCVD growth which offers high efficiency, low threshold current, and excellent reliability.
These devices are available in a High-Heat-Load package which has an integral thermoelectric cooler, thermistor, and monitor photodiode. They are also available on an open heatsink package, as well as other package options.
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 有限会社イーオーアール | ||
| 要問い合わせ | 株式会社オプトロンサイエンス | ||
| 要問い合わせ | 東京都 | 株式会社エムスクェア | |
| 要問い合わせ | 有限会社サンプラス | ||
