型番:8212A-1 メーカー:Analog Modules 商品コード:L003667

HIGH REPETITION RATE POCKELS CELL DRIVER

電圧: 0.7kV-2.0 kV
パルス幅: Min. 0.2µs、Max. 8000µs
重さ: 13.5 oz.

DESCRIPTION:
The Model 8212A-1 Pockels Cell/Shutter Driver is designed for high repetition rate, pulsed applications. Solidstate MOSFET technology is used, giving excellent trigger noise immunity and a smooth output waveform. This technique eliminates common problems associated with avalanche and transformer drivers. The Model 8212A has a rise and fall time of less than 7 ns at output voltages up to 2.0 kV and can operate at repetition rates up to 50 kHz with no additional cooling required. Much higher repetition rates are possible with appropriate cooling methods.

価格 地域 代理店
要問い合わせ 株式会社オプトサイエンス
