型番： 867A　メーカー：Analog Modules　商品コード：L003663

FLASHLAMP SIMMER SUPPLY

FLASHLAMP SIMMER SUPPLY
FLASHLAMP SIMMER SUPPLY

867A データシート.pdf

出力: -28W
電流: -150mA
電圧: -250V

DESCRIPTION:
The Model 867A simmer supply is designed to strike and maintain a low-level current discharge in flashlamps. Initially, the simmer output open circuit voltage rises to a stabilized 1125V. The simmer trigger output provides an SCR discharge of 350V at 20mJ to drive a trigger transformer. When the lamp is struck, the trigger pulses are inhibited and the supply provides a constant current to the flashlamp. Immediately after PFN discharge, the current is boosted automatically to maintain the arc. An external ballast is not normally required. For high pressure, long-arc lamps or dual lamps, Model 864A is recommended.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 株式会社オプトサイエンス
