型番：5705V-40-D、5705-I-40-DC、5705-V-100-D、5705-I-100-DC、5705-V-200-D、5705-I-200-DC 　メーカー：Analog Modules　商品コード：L003655

ISOLATED LASER DIODE POWER MODULE

出力: 1750W-2000W
電流: 10A-50A
パルス幅: <100μs
重さ: 3 lbs

DESCRIPTION:
The Model 5705 isolated laser diode power module uses a proprietary power conversion technique to charge energy storage capacitors for CW or pulsed diode pumped solid-state laser applications. A differentially isolated output allows the Model 5705 to be configured with either positive or negative output. With the addition of an internal Hall effect sensor, and with 280-360VDC input, the module can operate as a current source to deliver pulsed or CW current directly to diode loads. For applications requiring greater operational control, the Model 5705 can be operated as a voltage source and used with AMI's Model 779A or Model 7701A laser diode driver. The Model 5705 provides the highest power density of any similar module on the market and may easily be used with additional 5705 Series modules for even higher average power applications. The Model 5705 is designed to meet the isolation and leakage current requirements for the most stringent medical applications.

見積りBOXへ入れる欲しい物リストに登録

メーカーWebサイトへ

価格	地域	代理店
要問い合わせ		株式会社オプトサイエンス

ISOLATED LASER DIODE POWER MODULE
