型番： メーカー：QSI 商品コード：L000363
650nm Laser | 10mW
波長: 650nm-650nm
出力: 10mW-10mW
パッケージ: TO-can
テクノロジー: n/a
650nm The attached product specification sheet describes a QSI Laser device. This 650nm laser offers a threshold current of 50 mA and an operating current of 80 mA with an optical output power of 10mW. The operating voltage is spcecified at 2.6 V. Applications for this QSI Laser device include optical pick-up an laser module for bar code reader. Key features include a Package Type of TO-18 andBuilt-in Photo Diode for Monitoring the Laser Diode.
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 三基光学館 | ||
