波長: 790nm-810nm
出力: 100mW-200mW
パルス幅: < 40 fs
冷却方法: Air

< New generation of sub-40 fs fiber laser at 800 nm >
Ti-PULS, specially designed to seed Ti:Sapphire amplifier, is a new product completing our PULS product line. This laser benefits from our legacy in modelling, designing of innovative fiber laser sources and components. Based on all-PM fiber frequency doubled femtosecond mode-locked oscillator, our laser offers a unique, monolithic solution to seed Ti:Sapphire amplifiers, for applications in multiphoton imaging, and biophotonics.

< Features >
• Cost-effective alternative to existing Ti:Sapph seeders
• Air-cooled, compact, robust optical integration
• Environmentally stable output
• Lowest pulse duration and high pulse energy available for a fiber laser
• Laser customization

< Applications >
• Seeding Ti :Sapph lasers
• Biophotonics
• Ultrafast Time Domain Spectroscopy
• Multiphoton Microscopy
• Supercontinuum generation

< Options >
• Stretcher (> 200 ps), GVD post-compensation
• Fiber delivery
• 1600 nm & 800 nm output

< Technical Specifications >
(Optical)
Average power: > 100mW @ 40 MHz, > 200mW @ 80MHz
Spectral width: > 22 nm
Pulse duration: < 40 fs
Repetition rate: 40 MHz or 80MHz
M²: < 1.2
Ellipticity: > 0.92
Beam waist diameter: 2 - 5 mm
Output coupling: Free space (fibered delivery as an option)
Power stability: ~ 1% RMS
Polarization: Linear (PER > 20 dB)

(Electrical)
External interface: USB, RS232, output trigger
Software interface: ALPhANOV GUI, serial communication protocol
Compatibility & libraries: Ubuntu / Windows 7 / 10 ; DLLs-Hexa

(Mechanical)
Dimensions laser head / laser controller dimensions: 31 x 20 x 15 cm / 4U rack
