型番：VPSL-0690-035-x-5-A　メーカー：Blue Sky Research　商品コード：L003352

690nm / 35mW　VPS Laser Diode [TO-can]

波長: 680nm-695nm
出力: -35mW
電圧: 2.1V-2.8V
パッケージ: TO-can
形状: 円
拡がり角: 7, 8.5, 10.5 deg

< Description >
The VPSL-0690-035-x-5-A Laser Device is a 0.68 µm band, AlGalnP index guided, laser diode with a multi-quantum well (MQW) structure. It is suitable as a light source for large capacity optical disc memories, such as magneto-optical, and various other types of optical equipment. Combined with an integrated, internal, beam correcting optic and encased in a hermetic sealed package, this is a high-performance, highly reliable, and long life laser diode.

< Features >
Built-in monitor photodiode
Circular, diverging beam, NA approximately 0.11
Diffraction limited wavefront, aberration equal or better than λ/4 peak to valley
35mW (CW maximum) optical power, 50mW pulsed (50% duty, pulse < 1μs)
Standard 5.6 mm form factor
