型番：FiberMax830　メーカー：Blue Sky Research　商品コード：L003323

830nm / 25, 100mW　Fiber Pigtailed NIR Laser Module

830nm / 25, 100mW　Fiber Pigtailed NIR Laser Module
830nm / 25, 100mW　Fiber Pigtailed NIR Laser Module
830nm / 25, 100mW　Fiber Pigtailed NIR Laser Module
830nm / 25, 100mW　Fiber Pigtailed NIR Laser Module
830nm / 25, 100mW　Fiber Pigtailed NIR Laser Module
830nm / 25, 100mW　Fiber Pigtailed NIR Laser Module

FiberMax830 データシート.pdf

波長: 815nm-840nm
出力: 20mW-100mW
電流: 75mA-280mA
電圧: 1.3V-2.4V
テクノロジー: Fiber Pigtailed NIR Laser Module

< Description >
FiberMax830 is a fiber-pigtailed red laser module delivering superior performance for today’s demanding electro-optic applications. Based on Blue Sky Research laser packaging technology, the FiberMax830 provides excellent coupling efficiency and stability in a cost effective package. The thermally stable design of the FiberMax830, based on our standard FiberMAX packaging technology, is a proven, stable package with many thousands of lasers operating in demanding applications. The units are offered with Multimode, Polarization Maintaining Single Mode or Single Mode fiber, 3mm or 0.9mm jacketing and a range of collimator options.
