型番：FiberMax532　メーカー：Blue Sky Research　商品コード：L003318

532nm / 25mW　Fiber Pigtailed Green Laser Module

532nm / 25mW　Fiber Pigtailed Green Laser Module
532nm / 25mW　Fiber Pigtailed Green Laser Module
532nm / 25mW　Fiber Pigtailed Green Laser Module
532nm / 25mW　Fiber Pigtailed Green Laser Module
532nm / 25mW　Fiber Pigtailed Green Laser Module
532nm / 25mW　Fiber Pigtailed Green Laser Module

FiberMax532 データシート.pdf

波長: 531nm-533nm
出力: 1.0mW-25mW
電流: 300mA-450mA
電圧: -2.7V
テクノロジー: Fiber Pigtailed Green Laser Module

< Description >
FiberMax532 is a fiber-pigtailed green laser module delivering superior performance for today’s demanding electro-optic applications. Based on Blue Sky Research laser packaging technology, the FiberMax532 provides excellent coupling efficiency and stability in a cost effective package. The thermally stable design of the FiberMax532, based on our standard FiberMAX packaging technology, is a proven, stable package with many thousands of lasers operating in demanding applications. The units are offered with Multimode, Polarization Maintaining Single Mode or Single Mode fiber, 3mm or 0.9mm jacketing and a range of collimator options.
