型番：MWIR DFB 5.26 µm QCL C-Mount　メーカー：Adtech Optics, INC.　商品コード：L003233

5.26μm / 74.3mW　MWIR DFB QCL C-Mount

波長: 5.26μm-
出力: -74.3mW
電流: -0.44A
電圧: -12.8V
パッケージ: C-Mount
テクノロジー: MWIR DFB QCL

C - MOUNTED DEVICE
OVERVIEW
・Conductively Cooled
・CW Operation
・Mount Dimensions (approx): 6 x 6 x 4 mm (excluding leads)

(LASER SPECIFICATIONS)
Process: DFB
Oper. Temperature: 15 – 45 °C
Facet Coating: Front AR / Back HR

(ELECTRO–OPTICAL CHARACTERIZATION)
Driving Conditions;
Operation Mode: CW
Temperature: 15 °C

Electrical;
Thresh. Current: 0.29 A
Thresh. Voltage: 11.6 V
Laser Efficiency: 1.3%

Optical;
Center Wavelength: 5.26 µm

Tuning Range;
Temperature: 0.40 nm/K
Current: 46.0 nm/A

Beam Divergence;
Typ. Fast Axis: 60 deg
Typ. Slow Axis: 40 deg
