型番：Necsel NovaTru™ Chroma 647　メーカー：Necsel Communication＆Instrumentation Systems, Inc.　商品コード：L003196

Necsel NovaTru™ Chroma 647 Wavelength Stabilized Laser

Necsel NovaTru™ Chroma 647 Wavelength Stabilized Laser
Necsel NovaTru™ Chroma 647 Wavelength Stabilized Laser

出力: 200mW-300mW
ビーム径: 1 x 5 mm
拡がり角: 1 x 5 deg

This stabilized, narrow linewidth laser source is ideally suited for Raman spectroscopy. The small size, turn-key operation and simple interface also makes it a great choice for industrial, military and security applications.

< FEATURES & BENEFITS >
VBG Wavelength Stability
Compact, Small Box Design
Low Power Consumption
Digital & Analog Control Functions
Free-space or Fibered Outputs

< APPLICATIONS >
Raman Spectroscopy
Particle Sizing & Counting
Flow Cytometry
Metrology
LIDAR

< Operating Specifications >
Spectral linewidth：TYPICAL 1.3cm-1
Wavelength stability：TYPICAL +/- 5pm
ASE suppression (typical)**：TYPICAL 40dB
Optical power stability：TYPICAL < 1% pk-pk
Noise (10Hz–100MHz)：TYPICAL < 0.25%rms
Modulation-analog (typical)：NA
Modulation-digital (typical)：NA
Power adjustability：MIN 5%　MAX 100%

< Free Space Optical Specifications >
Beam quality (mˆ2 typical) vertical：TYPICAL 1.2
Beam quality (mˆ2 typical) horizontal：NA
Beam diameter vertical：TYPICAL 1mm
Beam diameter hortizontal：TYPICAL 5mm
Beam divergence—vertical：TYPICAL 1deg
Beam divergence—horizontal：TYPICAL 5deg
Polarization ratio：TYPICAL 100:1linear

< Electrical Specifications >
DC input (max)：TYPICAL 2A @ 5V
Warm-up time ：MIN 5sec　MAX 10sec
Power consumption：MIN 6W　MAX 9W
Case temperature：MIN -20℃　MAX 50°C
Humidity (non-condensing)：MIN5%　MAX95%

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 京都府 株式会社光響
