型番：Necsel Blue 445 Laser　メーカー：Necsel Communication＆Instrumentation Systems, Inc.　商品コード：L003180

Necsel Blue 445 5.5W Laser

Necsel Blue 445 5.5W Laser
Necsel Blue 445 5.5W Laser

波長: 440nm-449nm
出力: 5.5W-
電流: 2.1A-2.3A
電圧: 6.0V-9.6V

The Necsel Blue Laser contains direct emitting diodes and produces 5.5W of power. This laser has excellent power conversion efficiency and comes standard in a fiber-coupled package. For users who want to get started right away, combine this laser with the Necsel Blue Developer’s Kit.

< FEATURES & BENEFITS >
5.5W of Power
30,000 hours of Lifetime*
Direct Emitting Diode
Easily Modulated
Low Energy Consumption
Optional Free Space Design
Optional Developer’s Kit

< APPLICATIONS >
Digital Projection
Remote Source Lighting
Hazardous Lighting
Phosphor Illumination
Laser Light Shows
Medical
Forensics

< Specifications Summary >
Operating Power (CW)：Typical 5.5W
Module Operating Temperature [non-condensing atmosphere]：Typical 30℃
Center Wavelength [at 25°C and Pop]：Min. 440nm　Typical 445nm　Max.449nm
Wavelength Temperature Coefficient：Max. 0.1nm/℃
Threshold Current：Typical 350ｍA
Slope Efficiency：Typical 3.2W/A
Laser Power Conversion Efficiency：Typical 30％

< Driver Requirements >
Operating Voltage (2 in series)：Min. 6.0V　Typical 8.8V　Max. 9.6V
Allowable Reverse Current.：Max. 85ｍA

< Fiber-Coupling Options >
Connector Type (Nose length 0.3850 – 0.3863 in., 9.779 – 9.812 mm)：Typical SMA-905
Fiber Core Diameter (Centration ≤ 10 um)：Typical 0.400 or 0.200ｍｍ
Numerical Aperture：Typical 0.22
