型番:Necsel NovaTru™ Chroma 785 メーカー:Necsel Communication&Instrumentation Systems, Inc. 商品コード:L003587
出力: 20mW-50mW
ビーム径: 1 x 5 mm (Multi and Single Mode)
拡がり角: 0.8 x 1.3 mrad (Multi Mode)、1 x 5 deg (Single Mode)
These stabilized lasers combine high performance fiber optic packaging and compact laser drive circuit design for rapid integration into flow cytometers, interferometers, spectral instruments or laboratory research setups where reliable, stable single-mode laser performance is required. The integrated driver circuitry is versatile enough for many other potential sources as well.
< FEATURES & BENEFITS >
High Power Single Mode Performance
VBG Wavelength Stability
Ultra Stable Output Power
Fully Integrated OEM Solution
Very Low Power Consumption
Collimated or Fiber Coupled Output
User Selectable Control Options
Compact, Small Box Design
< APPLICATIONS >
Raman Spectroscopy
Flow Cytometry
Confocal Microscopy
Metrology
Fluorescence Excitation
Interferometry
Microlithography
HeNe Replacement
Particle Sizing & Counting
LIDAR
< Multimode Operating Specifications >
Output power:MIN 20mW MAX50mW
Spectral linewidth:TYPICAL < 50MHz
Wavelength stability:TYPICAL +/- 5pm
ASE suppression (typical)**:TYPICAL 40dB
Optical power stability:TYPICAL +/- 1% pk-pk
Noise (10Hz–100MHz):TYPICAL < 0.2%rms
Modulation-digital (typical):10kHz
Power adjustability:MIN50% MAX 100%
< Multimode Free Space Optical Specifications >
Beam quality (mˆ2 typical) vertical:TYPICAL 1.2
Beam quality (mˆ2 typical) horizontal:TYPICAL 1.1
Beam diameter vertical:TYPICAL 1mm
Beam diameter hortizontal:TYPICAL 5mm
Beam divergence—vertical:TYPICAL 0.8mrad
Beam divergence—horizontal:TYPICAL 1.3mrad
Beam Pointing Stability:TYPICAL< 50µrad
Polarization ratio:TYPICAL 100:1linear
< Multimode Electrical Specifications >
DC input (max):2A @ 3.3V
Warm-up time :TYPICAL < 5min
Power consumption:TYPICAL 5W
Case temperature:MIN -15℃ MAX 40°C
Humidity (non-condensing):MIN 5% MAX 95%
< Single Mode Operating Specifications >
Output power:MIN 500mW MAX 600mW
Spectral linewidth:TYPICAL 1.3cm-1
Wavelength stability:TYPICAL +/- 5pm
ASE suppression (typical)**:TYPICAL 40dB
Optical power stability:TYPICAL < 1% pk-pk
Noise (10Hz–100MHz):TYPICAL < 0.25%rms
Modulation-analog (typical):NA
Modulation-digital (typical):NA
Power adjustability:MIN 5% MAX 100%
< Single Mode Free Space Optical Specifications >
Beam quality (mˆ2 typical) vertical:TYPICAL 1.2
Beam quality (mˆ2 typical) horizontal:NA
Beam diameter vertical:TYPICAL 1mm
Beam diameter hortizontal:TYPICAL 5mm
Beam divergence—vertical:TYPICAL 1deg
Beam divergence—horizontal:TYPICAL 5deg
Polarization ratio:TYPICAL 100:1linear
< Single Mode Electrical Specifications >
DC input (max):2A @ 5V
Warm-up time:MIN 5sec MAX 10sec
Power consumption:MIN 6W MAX 9W
Case temperature:MIN -20°C MAX 50°C
Humidity (non-condensing):MIN 5% MAX 95%
