型番：Necsel Green 525 3.5W Laser　メーカー：Necsel Communication＆Instrumentation Systems, Inc.　商品コード：L003174

Necsel Green 525 3.5W Laser

Necsel Green 525 3.5W Laser
Necsel Green 525 3.5W Laser

波長: 520nm-530nm
出力: 3.5W-
電流: 1.65A-1.8A
電圧: 8V-30V

The Necsel Green Laser contains direct emitting diodes and produces 3.5W of power. This laser has a fast turn on time, excellent stability, and operates at a wide temperature range. For users who want to get started right away, combine this laser with the Necsel Green Developer’s Kit.

< FEATURES & BENEFITS >
3.5W of Power
400um Fiber Coupled
20,000 hours of Lifetime
Direct Emitting Diode
Fast Modulation
Wide Operating Temperature
Optional Free Space Design
Optional Developer’s Kit

< APPLICATIONS >
Digital Projection

< Specifications Summary >
Temperature：TYPICAL 30℃ MAX 35℃
Wavelength Range：MIN 520nm　TYPICAL 525nm　MAX 530nm

< Driver Requirements >
Operating Voltage (5 in series)：MIN 20V　TYPICAL 23V　MAX. 30V
Operating Voltage String 2 (3 in series)：MIN 12V　TYPICAL 14V　MAX 18V
Operating Voltage String 1 (2 in series)：MIN 8V　TYPICAL 9V　MAX 12V
Allowable Reverse Current：MAX 85mA

< Fiber-Coupling Options >
Connector Type (Nose length 0.3850 – 0.3863 in., 9.779 – 9.812 mm)：TYPICAL SMA-905
Fiber Core Diameter (Centration ≤ 10 um)：TYPICAL 0.400mm
Numerical Aperture：TYPICAL 0.22

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 京都府 株式会社光響
