型番: メーカー:Modulight,Inc. 商品コード:L000303

795nm, 40W Laser Diode

波長: 795nm-795nm
出力: 40W-40W
パッケージ: laser diode bar
テクノロジー: unmounted high power bar

795nm : 40W unmounted high-power laser diode bar from Modulight. The ML1278 series is an unmounted high-power laser diode bar (array) with a 30% fill factor, producing up to 40W CW of optical output power at 795nm wavelength. A member of the LumiLase product family, the ML1278 provides efficient and stable laser light output in CW and pulsed modes of operation. Adequate cooling should be ensured during operation. Key applications referenced on the attached data sheet include optical pumping, materials processing and aesthetic treatments. Also referenced are Illumination and surgical applications.

Key specifications include a specified operating current of 45 Amp for 40W and an operating voltage of 2V. The slope efficiency is greater than 1 W/A. Threshold current is specified at less than 9 Amps.

価格 地域 代理店
要問い合わせ 京都府 株式会社光響
