型番：5705　メーカー：　商品コード：L002872

2 kW Output Power, High Efficiency Laser Diode Driver

メーカー希望小売価格: Request Price 電流: 50A-50A

Product Overview:
The Model 5705 is a 2kW high power driver designed to allow you to chain multiple modules together for even higher power applications. It is an isolated laser diode power module uses a proprietary power conversion technique to charge energy storage capacitors for CW or pulsed diode-pumped solid-state laser applications.
The Model 5705 isolated laser diode power module uses a proprietary power conversion technique to charge energy storage capacitors for CW or pulsed diode-pumped solid-state laser applications. It is a differentially isolated output allows the Model 5705 to be configured with either positive or negative output.
The module can operate as a current source to deliver pulsed or CW current directly to diode loads with the addition of an internal Hall effect sensor, and with 280-360VDC input.
The Model 5705 can be operated as a voltage source and used with AMI's Model 779A or Model 7701A laser diode driver for applications requiring greater operational control. It provides the highest power density of any similar module on the market and may easily be used with additional 5705 Series modules for even higher average power applications.
The Model 5705 is designed to meet the isolation and leakage current requirements for the most stringent medical applications.

見積りBOXへ入れる欲しい物リストに登録

価格	地域	代理店
代理店が登録されていません

2 kW Output Power, High Efficiency Laser Diode Driver
