型番：　メーカー：Xiton Photonics GmbH 　商品コード：L002700

Q-Switched Laser, Nanosecond, 1064nm, 800µJ

Q-Switched Laser, Nanosecond, 1064nm, 800µJ
Q-Switched Laser, Nanosecond, 1064nm, 800µJ

波長: 1064nm-1064nm
テクノロジー: Q-Switched Laser

Q-switched laser with nanosecond pulse widths from Xiton Photonics. The q-switched solid state laser features a beam profile of TEM00, short pulse duration, and can be tailored to match your needs. Beam quality of M2<1.2 with pulse to pulse stability less then 0.3%. The 1064nm laser has a spectral width of 80MHz. The nanosecond laser pulse repetition interval is 8kHz to 15kHz with a pulse duration less then 12ns. Average pulse output power is greater then 8 watts. Q-Switched Laser with 800µJ energy output at a wavelength of 1064nm.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 株式会社日本レーザー
