型番：　メーカー：Powerlase Photonics Ltd　商品コード：L002477

Q-Switched Nanosecond Laser, 1064nm

Q-Switched Nanosecond Laser, 1064nm
Q-Switched Nanosecond Laser, 1064nm
Q-Switched Nanosecond Laser, 1064nm
Q-Switched Nanosecond Laser, 1064nm

波長: 1064nm-1064nm
出力: 1600W-1600W
テクノロジー: Q-Switched Laser

High power nanosecond laser from Powerlase Photonics. Diode pumped solid state laser uses q-switch technology to achieve pulse widths in the nanoseconds with output energies up to 250mJ at a repetition rate up to 25 kHz. Rugged DPSSL design for applications in Material Processing, Photovoltaic Processing, Thin Film Removal, Rapid Laser Patterning and Extreme Ultraviolet (EUV) Generation. Design of the laser provides excellent stability with condition monitoring. Beam quality of M2 30 with divergence of 12 mrad. Options for the q-switched laser include fiber delivery, remote controlled attenuation, and optimization of repetition frequency. DPSS laser with average output power up to 1.6 kW at a wavelength of 1064nm.
