型番:AP-1030 メーカー:AdValue Photonics 商品コード:L002442

1030nm / 100W EVERESTnano 1 µm Pulsed Fiber Laser

波長: 1030nm-1030nm
出力: 100W-100W
テクノロジー: Pulsed Fiber Laser
パルス幅: 5ns
冷却方法: Water cooled (portable chiller available as an option)

< Optical Characteristics >
Operation mode: Pulsed
Average power: 100 W (at 300 kHz)
Pulse repetition rate: 50 kHz to 500 kHz
Polarization: Random
Beam quality, M2: < 1.3
Output power stability: Within ±5%
Output delivery: Collimated output beam
(For custom requirements, please contact AdValue Photonics.)

< General Characteristics >
Operating temperature: +10 to +30 ˚C
Storage temperature: +5 to +70 ˚C
Power requirement: AC 100~240 V (50/60Hz) (operating with AdValue Photonics Control Unit)
Warm-up time: 10 minutes

< Features >
・All fiber design
・High pulse energy and peak power
・High repetition rate capability
・Near diffraction limited beam quality
・Rugged OEM package and compact size

< Applications >
・Laser marking/cutting/ablating
・General materials processing
・LIDAR
・Frequency Conversion
