型番： メーカー：FITEL 商品コード：L002400
1527nm-1610nm, 10mW butterfly
波長: 1527nm-1610nm
出力: 10mW-10mW
パッケージ: butterfly
テクノロジー: DWDM
1527nm-1610nm FRL15DDBx series of DFB laser module is designed for DWDM applications with 2.5Gbit/s direct modulation. The module is housed in an industry standard hermetically sealed 14-pin butterfly package, which contains optical isolator, thermoelectric cooler, power monitor photodiode. Precise wavelength selection is available according to
ITU-T grid with 50 GHz spaced wavelength allocation.
Features:
- Low Drive Current, High Slope Efficiency
- High Side Mode Suppression Ratio
- Selected Wavelengths According to ITU-T Grid
- 50GHz Spacing Available
- RoHS compliant package
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | 京都府 | 株式会社光響 | |
