型番: メーカー:VERTILAS GmbH 商品コード:L002378

VCSEL, 1310nm, 1490nm, 1550nm

波長: 1490nm-1490nm
出力: 1mW-1mW
パッケージ: TO-can, TOSA
テクノロジー: VCSEL

1490nm Single-mode VCSEL from Vertilas. 1Gbps to 10Gbps, Wavelengths available include: 1310nm, 1490nm, 1550nm, CWDM. The VERTILAS communications laser products are single-mode VCSEL diodes (Vertical Cavity Surface-Emitting Laser) operating at data rates from 1 Gbps up to 10 Gbps. Packaging options include TO, receptacles, pigtails and other customer specific solutions. This high-performance single-mode VCSEL technology features a very low threshold current and provides an optical output power of up to 4.0 mW. The lasers feature fast rise and fall times, low threshold voltage, excellent SMSR performance and extremely low power dissipation. This VCSEL is well suited for high-performance, single-mode and multi-mode communications solutions with a data-rate of up to 10G Gbps. The low drive current enables simplified system design and reduces power dissipation and system cost.

Key Features:
- Single-mode VCSEL
- TO-46 form factor
- 1 Gbps to 10 Gbps data rate product versions
- Operating temperature: -20 to +70 °C, extended –20 to +85°C
- Low power consumption: Sub 30 mW
- Enables SFF modules with sub 1 W power budget
- ow drive currents and low threshold voltage
- Integrated monitoring diode optional
- Various packaging and TOSA options
