型番： メーカー：InPhenix Inc. 商品コード：L002271
1310nm, 5mW, Diode Laser Chips
波長: 1310nm-1310nm
出力: 5mW-5mW
パッケージ: singulated chip
テクノロジー: Fabry-Perot
1310nm Uncooled Fabry-Perot Laser Diode Chips from InPhenix. (1310 nm/1550nm)
Features:
• Multiple Quantum Well (MQW) Active Layer Structure
• Low Threshold and Operating Current
• High Modulation Speed, up to 2.5 Gb/s
• Wide Operational Temperature Range
• Chip, and Chip on Carrier are Available
Applications:
• Optical Transmission
• Data Communication
• Local Optical Network
• FTTH (Fiber to the Home)
| 価格 | 地域 | 代理店 | |
|---|---|---|---|
| 要問い合わせ | INPHENIX ジャパン | ||
