型番：　メーカー：Finisar Corporation　商品コード：L002020

DFB, 10Gbps, 1528nm-1605nm

DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm
DFB, 10Gbps, 1528nm-1605nm

波長: 1528nm-1605nm
出力: 20mW-20mW
パッケージ: butterfly
テクノロジー: DFB Laser, 10Gbps, Direct Mod

1528nm-1605nm DM200-01 module uses a 10Gb/s directly modulated DFB chip co-packaged with an optical spectral re-shaper (OSR) element as shown in Figure 1. An optical isolator is included between the DFB and the OSR while a beam-splitter component and 2 photodetectors are configured to allow frequency locking. Lens#1(L1) is used to
collimate the DFB laser output and pass the beam through the splitter and OSR, prior to coupling into single-mode fiber using Lens#2 (L2). A second isolator is included in the fiber pigtail to minimize the effect of external back-reflections on module performance.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 株式会社マクニカ クラビス カンパニー
