型番：FP-1310-C5-2-2.5-xx-A-x-x 　メーカー：Applied Optoelectronics, inc.　商品コード：L001827

Coaxial Pigtail of MQW-FP Laser for low-cost high speed transmitters

Coaxial Pigtail of MQW-FP Laser for low-cost high speed transmitters
Coaxial Pigtail of MQW-FP Laser for low-cost high speed transmitters

FP-1310-C5-2-2.5-xx-A-x-x データシート.pdf

波長: 1270nm-1350nm
出力: 2.0mW-
電流: 25mA-60mA
パッケージ: 5.6-mm TO-style package with 1-meter SMF-28 Fiber Pigtail
テクノロジー: Fabry Perot Laser

【Description】

The FP-1310-C5-2-2.5-xx-A-x-x series of MultiQuantum Well (MQW) FP lasers have been designed for low-cost high speed transmitters. The devices feature high output power and wide operating temperature range. Their uncooled, hermetically sealed, coaxial fiberpigtailed packages are a cost-effective means of providing a high-speed light source for intermediate-reach and long-reach applications.


【Features】

Advanced Multiple Quantum Well (MQW) FP Laser Design
High-speed up to 2.5 Gbps
Engineered Specifically for digital transmitters
Low-Cost Uncooled Laser Technology
1-meter SMF-28 Fiber Pigtail
5.6-mm TO-style package with SMF pigtail


【Applications】

2.5 Gbps transmitters
Point-to-point optical links
