型番：FP-1310-C5-2-A-xx-A-x-x　メーカー：Applied Optoelectronics, inc.　商品コード：L001820

Coaxial Pigtail of MQW-FP Laser for CATV

波長: 1270nm-1350nm
出力: 2.0mW-
電流: 25mA-60mA
パッケージ: 5.6-mm TO-style package with SMF pigtail
テクノロジー: Fabry Perot Laser

【Description】

The FP-1310-C5-2-A-xx-A-x-x series of MultiQuantum Well (MQW) Fabry Perot lasers have been designed specifically for analog applications, especially CATV. The devices feature high output power, wide operating temperature range, and low distortion characteristics. Their uncooled, hermetically sealed, coaxial fiberpigtailed packages are a cost-effective means of providing a highly linear light source for short-reach and intermediate-reach analog transmission applications.

【Features】

Advanced Multiple Quantum Well (MQW) Fabry Perot (FP) Laser Design
Low Distortion: IMD2 max –45 dBc、 IMD3 max –55 dBc
Cost-effective Uncooled Laser Technology
5.6-mm TO-style package with SMF pigtail

【Applications】

CATV
Analog transmission
