型番：　メーカー：Ondax, Inc.　商品コード：L000017

Single Frequency Laser, 150mW

Single Frequency Laser, 150mW
Single Frequency Laser, 150mW
Single Frequency Laser, 150mW
Single Frequency Laser, 150mW

波長: 405nm-830nm
出力: 150mW-150mW
スペクトル幅: < 500kHz
パッケージ: OEM LASER MODULE
テクノロジー: single frequency laser

405nm-830nm are single frequency laser modules from Ondax. These Laser Modules incorporate the Ondax SureLock™ VHG-stabilized laser diode to deliver steady, single frequency performance in an ultra-compact footprint. Offering both computer and integrated user controls, the LM Series includes precision temperature and current controls to deliver better than 1m coherence length and 1% power stability with less than 1 minute warm-up. This tightly integrated package makes it the ideal choice for both OEM instrumentation and laboratory applications. The LM laser module is available in wavelengths from 405nm to 830nm.

Key features include single frequency, collimated TEM laser output with long coherence length (~1m) and remote computer and onboard user controls with integral LCD Display. Also, precision temperature and current stabilization in an ultra-compact footprint of 40mm x 42.5mm x 100mm. Plug and play operation and NoiseBlock™narrow-band ASE suppression filters and beamsplitters are available in matching wavelengths to further reduce linewidth and ASE noise

Key Applications:
• Raman Spectroscopy
• Interfereometry
• Metrology
• HeNe replacement
• Bio-instrumentation
• Particle Counting
• LIDAR
• Graphic Arts
• Sensing
• Analytical Instrumentation

For more information about Ondax products and the name of a local representative or distributor, visit www.ondax.com, email sales@ondax.com, or call (626) 357-9600.
