型番：　メーカー：Gooch & Housego　商品コード：L001609

980 NM Laser | 700mW

980 NM Laser | 700mW
980 NM Laser | 700mW
980 NM Laser | 700mW
980 NM Laser | 700mW
980 NM Laser | 700mW
980 NM Laser | 700mW
980 NM Laser | 700mW
980 NM Laser | 700mW

波長: 980nm-980nm
出力: 700mW-700mW
パッケージ: butterfly
テクノロジー: Grating Stabilized

980nm The attached device product sheet describes the following: The Gooch and Housego line of single mode, cooled 980 nm pump lasers deliver up to 750mW of fiber-coupled power. The modules are packaged using the unique, patent pending technology Uniline™ for permanent fiber alignment. Uniline™ provides superior end-of life optical and electrical performance, achieved by maintaining a highly stable, all-axis alignment lock between the laser chip and the tip of the single-mode fiber. The hermetically sealed 14 pin butterfly package is available with a fiber Bragg grating and includes thermoelectric cooler, thermistor, monitor photodiode and UniDry™ getter. The fiber Bragg grating precisely locks the center wavelength over extended power and temperature range. Center wavelengths in the range of 976 nm to 980 nm are available with tight wavelength control. EM4’s Uniline™ family of pump lasers are qualified to meet the requirements outlined in Telcordia GR-468-CORE.

見積りBOXへ入れる 欲しい物リストに登録
メーカーWebサイトへ
価格 地域 代理店
要問い合わせ 株式会社ハナムラオプティクス
要問い合わせ オーテックス株式会社
要問い合わせ 伯東株式会社
要問い合わせ 株式会社ニューメタルス エンド ケミカル コーポレーション
要問い合わせ 株式会社オプトサイエンス
